Voltage/Current
DC5V/2A (only TX power supply is needed)
Power consumption
TX+RX＜10W
HDMI compliance
HDMI 1.4
HDCP compliance
HDCP 1.4
HDMI resolution
800x600, 1024x768, 1280x720, 1280x960, 1366x768, 1440x900, 1680x1050, 1920x1080, 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@24/25/30/50/60Hz, 3840x2160@24/25/30Hz
Audio formats
DTS, DTS-HD, PCM, LPCM
HDR
Supported
Input and output TMDS signal
0.7~1.2Vp-p(TMDS)
Input and output DDC signal
5Vp-p(TTL)
Cat6/6A/7
1080p@60Hz transmission 70 meters
4K@30Hz transmission 40 meters
ESD
Implementation of the standard:
IEC61000-4-2
1a Contact discharge level 2（±4KV）
1b Air discharge level 3 (±8KV)
Working temperature
-20~60℃
Storage temperature
-30~70℃
Humidity (no condensation)
0～90%RH
Dimension
75.0(L) x 60.0(W) x 20(H) mm
Weight
TX: 123g RX: 123g
Color
Black
